Cantilever Racking System Kit

Heavy-Duty Cantilever Racking System

The ideal storage solution for long, bulky, and irregularly shaped materials such as lumber, pipe, tubing, steel, furniture, and building materials. Cantilever racking provides open-front storage with horizontal arms that allow easy loading and unloading by forklift or by hand.

This heavy-duty cantilever rack system is designed for warehouse, industrial, and commercial storage applications where standard pallet racking is not practical.

Customize your cantilever rack system with multiple shelf levels and arm lengths to fit your storage needs.

Available Options

• Shelf Levels: 3-Level, 4-Level, 5-Level, or 6-Level configurations
• Arm Lengths: 48″ or 60″ Width available
• Style: Single-sided or double-sided cantilever racking system

Each Kit Includes

• 2 – 12′ cantilever columns
• 2 – 48″ cantilever bases
• 3 – Horizontal braces
• 2 – X-brace set
• Cantilever arms based on shelf level selected:
  • 3 Shelf Levels = 6 Arms
  • 4 Shelf Levels = 8 Arms
  • 5 Shelf Levels = 10 Arms
  • 6 Shelf Levels = 12 Arms

For Double-Sided Configurations:
Add 2 additional bases and 2 additional arms per shelf level desired.

Product Specifications

Cantilever Column

• 12′ cantilever column
• Dimensions: 10″ x 5″
• Capacity: 17,000 lbs
• Finish Color: Green RAL 6001
• Weight: 250 lbs

Cantilever Base

• 48″ cantilever base
• Dimensions: 10″ x 5″
• Finish Color: Green RAL 6001
• Weight: 85 lbs

Cantilever Arms

• Available in 48″ length
• Dimensions: 5″ thick
• Capacity: 3,200 lbs per arm
• Finish Color: Orange RAL 2004
• Weight: 41 lbs each

Horizontal Braces

• 60″ or 48" cantilever horizontal braces
• Finish Color: Orange RAL 2004
• Weight: 14 lbs each

X-Brace Sets

• 60″ cantilever X-brace sets
• Finish Color: Orange RAL 2004
• Weight: 16 lbs each

Cantilever racking is commonly used for storing:

✔ Lumber and wood products
✔ Pipe and tubing
✔ Steel bar and metal stock
✔ Furniture and oversized inventory
✔ Building materials and long products
